The ADV7173KSTZ-REEL from Analog Devices is a high-performance digital video encoder that converts 4:2:2 YCrCb digital video into high-quality analog outputs, including NTSC, PAL, and SECAM formats. With six 10-bit DACs, programmable timing, and low-power CMOS architecture, this encoder delivers exceptional output quality for both consumer and industrial video applications.
Supporting both square pixel and CCIR-601 formats, and packaged in a space-efficient 48-pin LQFP, the ADV7173 is ideal for FPGA- and DSP-based systems that require legacy video output without sacrificing flexibility.
Let’s take a closer look at what makes this video encoder a standout choice for multimedia design.
Key Features of the ADV7173KSTZ‑REEL
Six High-Performance 10-Bit DACs
Ensures excellent video signal quality with wide dynamic range and low distortion.
Multi-Standard Output
Supports NTSC M/J, PAL B/D/G/H/I, and SECAM for maximum regional flexibility.
Square Pixel and CCIR-601 Compatibility
Integrates easily into both broadcast and workstation video architectures.
Programmable Subcarrier and Sync Timing
Complete control of video output through I²C for dynamic signal management.
Integrated On-Screen Display & Teletext Support
Ideal for overlays, captions, and the integration of broadcast metadata.
Low Power CMOS Technology
Reduces heat generation in embedded systems.
–40 °C to +85 °C Operating Range
Suitable for industrial and embedded applications.
48-Pin LQFP Package
Compact, surface-mount format for space-constrained boards.
Applications of the ADV7173KSTZ‑REEL
- Broadcast and studio video systems
- Consumer set-top boxes and media players
- Security and surveillance monitors
- Industrial video capture and overlay
- FPGA-based video systems
- Analog video output for legacy devices
