Hot Stock: XC5VLX85-1FF1153C

The XC5VLX85-1FF1153C is a high-performance FPGA from the Virtex-5 LX platform, purpose-built for general logic-intensive applications.

With 12,960 logic slices, 192 DSP48E slices, and support for up to 560 user I/Os, the XC5VLX85-1FF1153C delivers robust performance for data processing, embedded systems, and high-bandwidth logic design. Built on Xilinx's second-generation 65 nm ASMBL architecture, it balances high density, configurability, and speed. Read on to explore the key features and applications of Xilinx’s XC5VLX85-1FF1153C FPGA.

Key Features

High Logic Density

The XC5VLX85 delivers 12,960 configurable logic slices, making it ideal for compute-heavy tasks such as signal processing, algorithm acceleration, and multi-core coordination.

Advanced DSP48E Slices

With 192 DSP48E slices, the FPGA can efficiently execute multiply-accumulate (MAC) operations and bitwise logic, enabling powerful embedded DSP capabilities.

Flexible Memory Architecture

The XC5VLX85-1FF1153C includes 3,456 Kbits of block RAM, with 36 Kbit dual-port blocks configurable down to independent 18 Kbit segments. Its programmable FIFOs, ECC support, and byte-write capability improve performance and reliability.

Robust Clock Management

The six Clock Management Tiles (CMT) feature—each with 2 Digital Clock Managers (DCMs) and 1 Phase-Locked Loop (PLL)—enables jitter filtering, clock synthesis, and phase shifting.

High I/O Count and Wide Voltage Support

The FPGA offers up to 560 user configurable I/O pins with support for a wide range of signalling standards (LVTTL, LVCMOS, SSTL, HSTL, LVDS, etc.) and voltages from 1.2V to 3.3V.

Powerful Configuration and Security

The XC5VLX85-1FF1153C supports multiple configuration modes including SPI, BPI, SelectMAP, and JTAG, plus 256-bit AES encryption for secure bitstream loading.

System Monitoring Built-In

It includes a 10-bit ADC with on-chip sensors for temperature and voltage, enabling real-time health monitoring of the FPGA environment.

Applications

The XC5VLX85-1FF1153C is ideal for developers building high-speed, logic-rich systems across a range of sectors. Use cases include:

• Embedded control systems for industrial automation

• Communications infrastructure including switches and protocol converters

• Signal processing engines in aerospace and defence

• Custom logic emulation and prototyping

• Memory controllers and bus interface management

• Medical imaging and instrumentation platforms

Why Choose Component Sense?

Engineered for demanding digital designs, the XC5VLX85-1FF1153C offers the versatility and processing power needed for complex logic systems in embedded, industrial, and communications applications. At Component Sense, we ensure quick and dependable access to components like the XC5VLX85-1FF1153C to keep your electronic projects running smoothly. Here is why we are the best choice for your sourcing needs:

• Our vast inventory of over 150,000 stock lines helps you find the parts you need, exactly when you need them. Explore our full inventory here to source what you need to complete your BOM (bill of materials).

• With our industry-leading inspection process, we guarantee that every component we provide is fully traceable and 100% authentic. Additionally, all our brand-new parts are sourced exclusively from tier-one OEM and EMS companies, providing confidence in their reliability and security for your supply chain.

• At Component Sense, we are committed to promoting sustainability by supporting a circular economy in electronics manufacturing. By sourcing components from us, you help reduce the demand for new component manufacturing and actively minimise electronic waste that would otherwise end up in landfills.

• Backed by over 23 years of industry experience, our team of experts is here to support your project needs. We aim to respond to all quote requests within 20 minutes, providing fast, reliable service.

• We offer fast shipping with a 95% on-time delivery rate and same-day international shipping for most of our stock.

At Component Sense, we combine exceptional support, 100% counterfeit-free components, and fast shipping. Click below to order the XC5VLX85-1FF1153C and experience five-star service.
