The CYUSB3314-88LTXIT from Infineon (previously Cypress Semiconductors) is a high-speed, multi-port USB 3.0 hub controller that supports USB 2.0 and USB 3.0 connectivity simultaneously. Part of the Cypress HX3 family, it enables low-power, high-bandwidth USB expansion for consumer electronics, embedded systems, and industrial applications.
This quad-port SuperSpeed hub supports Low-Speed, Full-Speed, High-Speed, and SuperSpeed (5 Gbps) USB operations in a single compact 88-pin QFN package. It integrates a USB 3.0 hub, USB 2.0 hub, configuration options, power management, and multiple downstream ports, all without the need for external glue logic.
Let’s take a closer look at what makes this controller a reliable choice for next-generation USB system design.
Key Features of the CYUSB3314-88LTXIT
USB 3.0 SuperSpeed Hub (5 Gbps)
Supports USB 3.0 with full backward compatibility to USB 2.0 and USB 1.1 devices
Four Downstream USB Ports
Provides a 1-up / 4-down hub architecture with integrated USB 3.0 & USB 2.0 PHYs
Low-Speed, Full-Speed, High-Speed & SuperSpeed Support
Ensures complete compatibility across all USB device classes.
Integrated USB 2.0 Hub
Embedded USB 2.0 PHY for seamless management of legacy USB devices.
Multiple Configuration Options
Flexible configuration via I²C EEPROM, pins, or Cypress configuration utility.
Power Management Features
Includes port power control, over-current detection, and USB-IF compliant power behaviour.
Low-Power Architecture
Advanced power-saving modes, including suspend and selective suspend.
88-Pin QFN Package
Compact footprint designed for high-density PCB layouts.
Industrial Temperature Range
Guaranteed performance from –40 °C to +85 °C.
Applications of the ADV7173KSTZ‑REEL
- USB 3.0 docking stations & port replicators
- Monitors and display hubs
- Set-top boxes & media players
- Industrial USB expansion modules
- PC motherboards & embedded systems
- Printers, scanners, and imaging equipment
- Multi-function consumer devices
